Comfy and secure with a 38°C safety stop to prevent water from getting too hot and a “cold touch” feature to ensure a safe temperature on the mixer bar. The built-in shelf keeps shampoo within reach.
Width: 265 mm
Depth: 100 mm
Length : 39 cm
Width : 12 cm
Height : 7 cm
Diameter :
Gross Volume : 3.1 l
Thermostat housing/ Handle: Zinc, Chrome-plated
Check the temperature control on a regular basis, adjust if necessary according to the assembly instructions.
Clean with a soft damp cloth only using water and a mild washing-up detergent or soap. Never use scouring powder, steel wool, a descaling agent or a detergent that is acidic or contains alcohol or an abrasive.
Separate flow and temperature controls.
You can override the safety stop temperature by pressing the override button.
Assembly and installation
150 mm fixed inlet centres.
What’s included
Wall fittings included.
Additional information
The thermostatic mixer is pre-set to a safety stop temperature of 38 °C. Since operating conditions in each supply system varies, it might be necessary to calibrate the mixer according to the service and installation instructions.
Recommended hot water temperature: 60°-65°C/140°F-149°F.
Recommended cold water temperature: 10-15°C/50°F-59°F.
Spare parts are available to prolong the life of your product. For more information, contact IKEA Customer Services at your IKEA store or IKEA.com.
Additional information
Max. temperature hot water system 80°C/176°F.
Safety and compliance
The thermostatic shower mixer can be used in high pressure systems. Tested to manage a pressure of max. 10 bar (1000 kPa). Recommended working pressure: 1.0 - 5.0 bar (100 kPa - 500 kPa).
Combine and complete
May be combined with head and hand shower kit or riser rail with hand shower.
A 38°C safety stop button prevents water from getting too hot and accidentally causing burns. Hotter temperatures can be reached by pressing the override button on the temperature control.
The shower mixer has a “cold touch” feature. Thanks to the anti-scald technology, the surface of the mixer bar never heats up and is always safe to touch.
The built-in shelf on the shower mixer is perfect for all those tall shampoo bottles that are often tricky to store in the shower.
Chrome-plated brass is a hard and durable surface that is easy to clean.
Coordination
Everything you need for a great shower experience
Our shower range offers everything you need for a pleasant shower. The thermostatic shower mixers come with “cold touch” and anti-scald technology. The head and hand showers come with different spray functions and a pressure compensating function that reduces water- and energy-use by up to 30%. There is a range of coordinated bathroom accessories that keep all those bottles off the floor. Add to this, a 10-year guarantee on the thermostatic mixers and a 3-year guarantee on riser rails, hoses, head and hand showers.
Function/solution
Designed with safety in mind
IKEA thermostatic shower mixers have a 38°C safety button that must be deliberately pressed to reach higher temperatures, but will never exceed 46°C – which is safe for human skin. Another smart feature is the “cold touch”, anti-scald technology which ensures that the shower mixers will never heat up or cause burns. Whether the preference is modern or more traditional style, IKEA shower mixers offer a great shower experience with highest safety in mind.
Material
What are zinc and zamak?
Zinc is a metallic element while zamak is a mixture of zinc, aluminium, magnesium and copper. Both are durable materials and easy to cast into different shapes. They are good at conducting heat and electricity. Objects made of zinc or zamak are often given a surface treatment to resemble metals like gold, brass or stainless steel. Both zinc and zamak retain their good properties when they are recycled to become new objects.
